Rear Hyundai I30N DBA3149S Brake Discs 314x20mm Street T2 Slotted New

Description

Rear Hyundai I30N DBA3149S Brake Discs 314x20mm Street T2 Slotted New

Rear Hyundai I30N DBA3149S Brake Discs 314x20mm Street T2 Slotted New

Feature Description	Advantage	Benefit
‘T3 Slot 48 precision CNC machined slots’	Tri-Symmetrical curve slots dampens the vibration harmonics or noise Increased number of out-gassing exit points for brake pad friction gasses to escape through Universal slot design	A quieter, responsive and smoother brake pedal feel Increases the consistency and effectiveness of every brake stop Eliminates the need for left and right discs
Kangaroo Paw – 144 diamond and tear drop pillar ventilation system	Increased surface area resulting in greater heat dissipation Increased surface area resulting in greater heat dissipation	Minimises brake fade and increases braking effectiveness Prolongs service life for both pads and rotors. Reduces mechanical damage and associated costs
XG150 High Carbon Alloyed Iron	An increase in thermal capacity property allows the rotor to handle constant extremes of heat over extended periods of time	Minimises warping and cracking and prolongs the service life of the rotor
Thermal Stability Profiling	Special formulation designed to respond to DBA’s TSP process	Minimises warping and cracking and prolongs the service life of the rotor
Thermographic Temperature Monitoring	Heat paint markings change colour at specific temperature thresholds When temperature thresholds are exceeded paint markings will permanently change colours	Offers the driver a clear indication of peak braking temperatures Allows the driver to monitor rotor fatigue and decide on rotor replacement and to assist resellers with warranty claims
Paint protection on non-friction areas	Reduces corrosion Enhances appearance	Stops any unsightly rust formation Adds value to the product

What is included:

• 2x pcs(1pair) Rear DBA3149S 314x20mm Brake Discs Street series T2 Slotted New (OEM Hyundai product code:58411S0500) New

Price includes 2 brake discs(1pair)

Technical Information:

• Diameter [MM]:314
• Disc Vent:Kangaroo Paw
• Number Of Holes:5
• Inner Diameter [MM]:76
• Min. Thickness [MM]:18
• Thickness [MM]:20
• Height [MM]:33
• Weight [KG]:6.6

Application:

Make                              Model   Year        Variant  Category                                        Note                                  Details

• HYUNDAI Kona N                  2021-    0 Turbo 2756BHP (2021-)                                        Rear                       Brake Pads: DB15013
• HYUNDAI i-30 N PD             2017-    0 Turbo 247BHP (2017-)                                           Rear                       Brake Pads: DB15013
• HYUNDAI i-30 N PD             2017-    0 Turbo 271BHP Performance Package (2017-)   Rear                       Brake Pads: DB15013
• HYUNDAI i-30 N PD             2021-    0 Turbo 280BHP Performance Package (2021-) Rear                       Brake Pads: DB15013
